Technical details
Pallet type: 800 x 1200 mm
Design
Built-in display: Yes
Display diagonal: 8.89 cm (3.5")
Product colour: Grey, Black
Control type: Buttons, Touch
Colour display: Yes
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power source type: AC
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 20 - 80%
Operating temperature (T-T): 5 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 1.77 kg
Width: 119 mm
Depth: 224 mm
Height: 176 mm
System requirements
Windows operating systems supported: Windows 11, Windows 10
Server operating systems supported: Windows Server 2016, Windows Server 2019, Windows Server 2022
Linux operating systems supported: Yes
Performance
Built-in barcodes: EAN13, Code 128 (A/B/C), EAN8, MaxiCode, UPC-A, Code 93, Code 39, Data Matrix, QR Code, CODABAR (NW-7), UPC-E, AZTECCODE, GS1 DataBar, MSI, Micro QR Code, POSTNET
Flash memory: 64 MB
Internal memory: 256 MB
Packaging data
Package weight: 2.9 kg
Package width: 306 mm
Package depth: 181 mm
Package height: 325 mm
Packaging content
Cables included: AC, USB
Ports & interfaces
Wi-Fi: No
Connectivity technology: Wired
Ethernet LAN: Yes
USB port: Yes
Other features
Spare part retention: 5 year(s)
Country of origin: Vietnam
Warranty period: 3 year(s)
Printing
Colour: No
Maximum resolution: 203 x 203 DPI
Print technology: Direct thermal
Maximum printing width: 5.9 cm
Minimum print length: 6.4 mm
Print speed: 152 mm/sec
Logistics data
Layers per pallet: 5 pc(s)
Pallet gross height: 17.5 cm
Master (outer) cases per pallet: 20 pc(s)
Products per pallet: 60 pc(s)
Pallet gross weight: 631.2 kg
Master (outer) cases per pallet layer: 4 pc(s)
Paper handling
Core diameter: 3.81 cm
Media thickness: 0.058 - 0.279 mm
