Technical details
Pallet type: 800 x 1200 mm
Design
Display: LCD
Built-in display: Yes
Product colour: Black, Grey
Colour display: Yes
Control type: Buttons, Touch
Power
AC input voltage: 100 - 240 V
AC adapter output voltage: 24 V
USB port voltage: 5 V
AC adapter output current: 3.6 A
USB port current: 3 A
AC input frequency: 50/60 Hz
Power source type: AC
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 5 - 40 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Height: 325 mm
Depth: 306 mm
Weight: 1.86 kg
Width: 181 mm
System requirements
Windows operating systems supported: Windows 11, Windows 10
Mobile operating systems supported: Android, iOS
Linux operating systems supported: Yes
Performance
Built-in barcodes: Code 93, AZTECCODE, QR Code, UPC-A, MSI, Code 128 (A/B/C), EAN8, Code 39, Micro QR Code, MaxiCode, EAN13, Data Matrix, CODABAR (NW-7), UPC-E, GS1 DataBar, POSTNET
Internal memory: 256 MB
Security algorithms: WPA2-PSK, EAP-FAST, EAP-TLS, WPA-PSK, 64-bit WEP, EAP-TTLS, 128-bit WEP, WPA3-SAE, PEAP
Number of fonts: 10
Page description languages: Raster_P, ESC P
Packaging data
Package weight: 2.9 kg
Package depth: 181 mm
Package width: 306 mm
Package height: 325 mm
Packaging content
Cables included: USB
Ports & interfaces
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, 802.11b, 802.11g
Wi-Fi: Yes
Connectivity technology: Wired & Wireless
USB 2.0 ports quantity: 1
USB port: Yes
Ethernet LAN: Yes
Bluetooth: Yes
Bluetooth version: 5.2+EDR
RS-232 ports: 1
Other features
Country of origin: Vietnam
Spare part retention: 5 year(s)
Warranty period: 3 year(s)
Printing
Print technology: Direct thermal
Colour: No
Maximum printing width: 5.9 cm
Maximum resolution: 203 x 203 DPI
Print speed: 152 mm/sec
Minimum print length: 6.4 mm
Logistics data
Pallet gross weight: 631.2 kg
Master (outer) cases per pallet: 20 pc(s)
Products per pallet: 60 pc(s)
Master (outer) cases per pallet layer: 4 pc(s)
Pallet gross height: 17.8 cm
Layers per pallet: 5 pc(s)
Paper handling
Maximum roll diameter: 12.7 cm
Ribbon length: 3 m
Media thickness: 0.058 - 0.279 mm
Maximum label length: 3 m
