Technical details
Pallet type: 800 x 1200 mm
Design
Display: No
Product colour: White, Grey
Built-in display: No
Power
Auto power off: Yes
Operational conditions
Operating temperature (T-T): 10 - 90 °C
Storage relative humidity (H-H): 20 - 85%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 5 - 40%
Weight & dimensions
Weight: 3.06 kg
Height: 255 mm
Width: 267 mm
Depth: 335 mm
System requirements
Server operating systems supported: Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2008 R2
Windows operating systems supported: Windows 8, Windows 7, Windows 8.1, Windows 10
Mobile operating systems supported: iOS 12, Android 5.0, Android 5.0, iOS 9.0, iOS 9.0, iOS 9.0, iOS 9.0, Android 4.0, Android 4.0, Android 4.0, Android 4.0, Android 4.0, Android 4.0, Android 7.0, Android 7.0, Android 7.0, iOS 8.0, iOS 8.0, iOS 8.0, iOS 8.0, iOS 8.0, iOS 11.0, Android 6.0, iOS 10.0, Android 8.0, Android 9.0
Linux operating systems supported: Yes
Performance
Font styles: Brougham,Brussels,Helsinki,Letter Gothic,San Diego
Flash memory: 64 MB
Number of fonts: 6
Internal memory: 256 MB
Page description languages: Raster_P, ZPL II, ESC P
Packaging data
Package weight: 3.98 kg
Quantity per pack: 1 pc(s)
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Cables included: AC, USB
Starter roll included: Yes
Warranty card: Yes
Software development kit (SDK): Yes
Ports & interfaces
Connectivity technology: Wired
Bluetooth: No
USB 2.0 ports quantity: 1
USB port: Yes
Wi-Fi: No
RS-232 ports: 1
Ethernet LAN: No
Other features
Country of origin: China
Spare part retention: 5 year(s)
LED indicators: Error, Power, Status
Languages support: Dutch, Czech, Spanish, Hungarian, Finnish, Swedish, Turkish, French, German, Polish, Japanese, Russian, English, Italian, Simplified Chinese, Portuguese, Norwegian, Danish
Date & time printing: Yes
Number of languages: 18
Printing
Colour: No
Maximum resolution: 203 x 203 DPI
Print technology: Direct thermal
Mirror printing: Yes
Print speed: 203 mm/sec, 8 lpm
Maximum print length: 3 m
Text style: Bold, Normal, Shadow, Italic, Horizontal lines, Shadow light, Surround, Invert
Maximum print height: 10.4 cm
Logistics data
Master (outer) cases per pallet: 40 pc(s)
Master (outer) cases per pallet layer: 8 pc(s)
Layers per pallet: 5 pc(s)
Pallet gross height: 14.2 cm
Pallet gross weight: 177.2 kg
Harmonized System (HS) code: 84433210
Products per pallet: 40 pc(s)
Paper handling
Core diameter: 1.27 cm
Maximum roll diameter: 12.7 cm
Maximum label width: 11.8 cm
