Technical details
Pallet type: 1200 x 1000 mm
Design
Built-in display: No
Display: No
Product colour: Black
Control type: Buttons
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 25 - 85%
Storage temperature (T-T): -40 - 60 °C
Weight & dimensions
Height: 370 mm
Width: 350 mm
Weight: 9.42 kg
Depth: 530 mm
System requirements
Mac operating systems supported: Mac OS X 10.11 El Capitan, Mac OS X 10.14 Mojave, Mac OS X 10.15.3 Catalina, Mac OS X 10.13 High Sierra, Mac OS X 10.15 Catalina, Mac OS X 10.12 Sierra
Windows operating systems supported: Windows 8.1, Windows 10
Server operating systems supported: Windows Server 2019, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Linux operating systems supported: Yes
Mobile operating systems supported: Android, iOS
Performance
Flash memory: 128 MB
Internal memory: 128 MB
Built-in barcodes: Industrial 2/5, Code 49, AZTECCODE, Code 128 (A/B/C), Code 93, QR Code, EAN13, Data Matrix, ITF-14, EAN8, MaxiCode, Interleaved 2/5, TLC39, CODABAR (NW-7), PDF417, UPC-E, GS1 DataBar, MicroPDF417, Code 39, EAN128
Number of fonts: 8
Page description languages: DPL, ZPL II, EPL2
Packaging data
Package weight: 11 kg
Packaging content
Cables included: AC, USB
Software development kit (SDK): Yes
Ports & interfaces
Wi-Fi: No
RS-232 ports: 1
USB port: Yes
Connectivity technology: Wired
Ethernet LAN: Yes
Other features
Country of origin: Taiwan
LED indicators: Error, Power, Status
Languages support: English, Portuguese, Swedish, German, Norwegian, Dutch, Spanish, Italian, French, Danish, Finnish
Printing
Colour: No
Print technology: Direct thermal / Thermal transfer
Print speed: 254 mm/sec
Maximum printing width: 10.7 cm
Maximum resolution: 203 x 203 DPI
Maximum print length: 25.4 m
Minimum print length: 5 mm
Logistics data
Pallet gross height: 16.3 cm
Layers per pallet: 4 pc(s)
Master (outer) cases per pallet: 20 pc(s)
Products per pallet: 20 pc(s)
Harmonized System (HS) code: 84433210
Master (outer) cases per pallet layer: 5 pc(s)
Pallet gross weight: 238.4 kg
Paper handling
Ribbon length: 450 m
Maximum roll diameter: 20.3 cm
Core diameter: 7.62 cm
Ribbon width: 4 cm
Maximum label width: 12 cm
