Technical details
Pallet type: 1200 x 1000 mm
Design
Built-in display: No
Display: No
Product colour: Black
Control type: Buttons
Weight & dimensions
Weight: 9.42 kg
Width: 370 mm
Depth: 525 mm
Height: 360 mm
System requirements
Windows operating systems supported: Windows 8.1, Windows 10
Mac operating systems supported: Mac OS X 10.7 Lion, Mac OS X 10.9 Mavericks, Mac OS X 10.3 Panther, Mac OS X 10.8 Mountain Lion, Mac OS X 12.0 Monterey, Mac OS X 10.6 Snow Leopard, Mac OS X 10.2 Jaguar, Mac OS X 13.0 Ventura, Mac OS X 10.5 Leopard, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Mobile operating systems supported: iOS 9.0, Android 5.0, Android 5.0, iOS 9.0, iOS 9.0, iOS 9.0, iOS 10.0, iOS 14, iOS 14, iOS 12, Android 6.0, Android 10.0, Android 10.0, Android 7.0, Android 7.0, Android 7.0, Android 12.0, iOS 11.0, iOS 11.0, Android 8.0, Android 8.0, iOS 13, iOS 13, Android 9.0, Android 11.0
Server operating systems supported: Windows Server 2012 R2, Windows Server 2016
Linux operating systems supported: Yes
Performance
Flash memory: 128 MB
Built-in barcodes: CODABAR (NW-7), UPC-E, EAN13, Code 11, UPC-A, ITF-14, MSI, Code 49, Code 128 (A/B/C), Deutsche Post Identcode, EAN8, Interleaved 2/5, TELEPEN, Code 93, Deutsche Post Leitcode, EAN128, EAN14, LOGMARS, POSTNET
Internal memory: 128 MB
Packaging data
Package weight: 11 kg
Packaging content
Cables included: AC, USB
Ports & interfaces
Connectivity technology: Wired
Wi-Fi: No
Ethernet LAN: Yes
RS-232 ports: 1
USB port: Yes
Other features
Country of origin: Taiwan
Printing
Maximum resolution: 203 x 203 DPI
Colour: No
Print technology: Direct thermal
Maximum printing width: 10.7 cm
Print speed: 152 mm/sec
Logistics data
Master (outer) cases per pallet: 20 pc(s)
Pallet gross weight: 242.4 kg
Master (outer) cases per pallet layer: 5 pc(s)
Products per pallet: 20 pc(s)
Layers per pallet: 4 pc(s)
Pallet gross height: 16.7 cm
Paper handling
Maximum media length: 25.4 m
Maximum label width: 12 cm
Safety warning
Warnings: Protect the unit from ingress of foreign objects, liquids and dust to prevent damage., Watch out for moving parts of the printer to avoid injury., Avoid contact with hot parts of the printer, may cause burns.
