Technical details
Pallet type: 1200 x 1000 mm
Design
Product colour: Black
Display diagonal: 8.89 cm (3.5")
Control type: Buttons, Touch
Colour display: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 25 - 85%
Weight & dimensions
Width: 350 mm
Depth: 530 mm
Weight: 9.42 kg
Height: 370 mm
System requirements
Mobile operating systems supported: iOS, Android
Server operating systems supported: Windows Server 2019, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported: Windows 8.1, Windows 10
Mac operating systems supported: Mac OS X 10.15.3 Catalina, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.13 High Sierra, Mac OS X 10.15 Catalina, Mac OS X 10.11 El Capitan
Linux operating systems supported: Yes
Performance
Built-in barcodes: Industrial 2/5, Code 49, EAN13, Data Matrix, Code 128 (A/B/C), EAN8, MaxiCode, Interleaved 2/5, TLC39, Code 93, QR Code, ITF-14, CODABAR (NW-7), PDF417, UPC-E, GS1 DataBar, MicroPDF417, AZTECCODE, Code 39, EAN128
Flash memory: 128 MB
Internal memory: 128 MB
Number of fonts: 8
Page description languages: EPL2, DPL, ZPL II
Packaging data
Package weight: 11 kg
Packaging content
Cables included: AC, USB
Software development kit (SDK): Yes
Ports & interfaces
Connectivity technology: Wired
RS-232 ports: 1
Ethernet LAN: Yes
Wi-Fi: No
USB port: Yes
Other features
Country of origin: Taiwan
LED indicators: Error, Power, Status
Languages support: Dutch, Spanish, Italian, Norwegian, French, Portuguese, Danish, Finnish, German, Swedish, English
Printing
Colour: No
Maximum resolution: 203 x 203 DPI
Print technology: Direct thermal / Thermal transfer
Maximum print length: 25.4 m
Minimum print length: 5 mm
Maximum printing width: 10.7 cm
Print speed: 254 mm/sec
Logistics data
Layers per pallet: 4 pc(s)
Pallet gross height: 16.3 cm
Harmonized System (HS) code: 84433210
Master (outer) cases per pallet: 20 pc(s)
Master (outer) cases per pallet layer: 5 pc(s)
Products per pallet: 20 pc(s)
Pallet gross weight: 237.2 kg
Paper handling
Core diameter: 7.62 cm
Maximum roll diameter: 20.3 cm
Ribbon length: 450 m
Ribbon width: 4 cm
Maximum label width: 12 cm
