Design Product colour: White On/off switch: Yes Cooling type: Active Fan diameter: 12 cm
Power AC input voltage: 100 - 240 V Input current: 11 - 5.5 A AC input frequency: 50/60 Hz Power protection features: Short circuit, Under voltage, Over current, Overheating, Over power, Over voltage Combined power (+12V): 744 W Max output current (+5Vsb): 3 A Combined power (-12V): 3.6 W Combined power (+3.3V): 100 W Max output current (+12V): 62 A Max output current (-12V): 0.3 A Total power: 750 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Max output current (+3.3V): 20 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Depth: 150 mm Width: 140 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX Bearing technology: Hypro Bearing Mean time between failures (MTBF): 100000 h ATX version: 3.1
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (12+4 pin) cable length: 700 mm PCI Express power connectors (12+4 pin): 1 Number of SATA power connectors: 3 Motherboard power cable length: 61 cm PCI Express power connectors (6+2 pin): 2 Cabling type: Fully-Modular SATA power cable length: 750 mm CPU power cable length: 75 cm Peripheral (Molex) power cable length: 690 mm CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX
