Features Supported video modes: 2160p Wall mountable: Yes Maximum resolution: 4096 x 2160 pixels Electrostatic Discharge (ESD) protection: Yes HDCP: Yes LED indicators: Yes Material: Metal Bandwidth: 18 Gbit/s Type: AV transmitter & receiver HDCP version: 1.4/2.2 Cable types supported: Cat6 Maximum transfer distance: 200 m Product colour: Black Maximum refresh rate: 60 Hz
Power Output current: 1 A Power consumption (transmitter) (max): 3.5 W Power consumption (receiver) (max): 2.5 W Power source type: DC External power adapter: Yes Operating voltage (transmitter): 5 V Operating voltage (receiver): 5 V
Operational conditions Operating temperature (T-T): -20 - 60 °C
Weight & dimensions Receiver weight: 154 g Receiver dimensions (WxDxH): 94 x 97 x 24 mm Transmitter dimensions (WxDxH): 94 x 97 x 24 mm Transmitter weight: 156 g
Packaging data Package height: 80 mm Package width: 149 mm Package weight: 620 g Package depth: 199 mm
Packaging content Cables included: IR Quick start guide: Yes AC adapter included: Yes
Ports & interfaces RJ-45 input ports: 1 HDMI version: 2.0 3.5 mm (1/8-inch) in: Yes USB ports quantity: 2 DC-in jack: Yes Number of HDMI outputs: 1 USB connector type: Micro-USB HDMI in: 1 3.5 mm (1/8-inch) out: Yes Connectivity technology: Wired Remote (IR) output: 1 RJ-45 output ports: 1 Remote (IR) input: 1
