Design
Fan diameter: 12 cm
Product colour: Black
On/off switch: Yes
Power
Maximum input current (@110V): 9 A
Max output current (+5Vsb): 3 A
Maximum input current (@220V): 4.5 A
Power protection features: Short circuit, Over voltage, Over current, Surge and inrush
Max output current (-12V): 0.3 A
Max output current (+3.3V): 20 A
AC input voltage: 100 - 240 V
Total power: 750 W
Input current: 9 - 4.5 A
Max output current (+5V): 20 A
Power factor: 0.9
Power Factor Correction (PFC) type: Active
Max output current (+12V1): 62.5 A
AC input frequency: 50/60 Hz
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Weight: 1.49 kg
Performance
Power supply unit (PSU) form factor: ATX
Purpose: PC/Server
80 PLUS certification: 80 PLUS Gold
ATX version: 3.0
Supported motherboard form factors: ATX
Ports & interfaces
Peripheral (Molex) power cable length: 550 mm, 850, 650 mm, 750
Number of SATA power connectors: 9
Motherboard power connector: 20+4 pin ATX
ATX power connector (20+4 pin): Yes
EPS power connector (4+4 pin): Yes
CPU power cable length: 60 cm
Motherboard power cable length: 60 cm
Cabling type: Fully-Modular
SATA power cable length: 550, 750, 650 mm
PCI Express power connectors (16-pin): 1
Safety warning
Hazard pictogram(s): GHS02: Flammable, GHS09: Environmental hazard, GHS07: Harmful
