Design Product colour: Black On/off switch: Yes Cooling type: Active Fan diameter: 14 cm Number of fans: 1 fan(s) Fan location: Top
Power Combined power (+5V): 120 W Max output current (-12V): 0.3 A Max output current (+3.3V): 22 A Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Overload Power Factor Correction (PFC) type: Active Max output current (+5V): 22 A Total power: 650 W Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 120 W Max output current (+12V): 54.2 A Power factor: 0.9 Efficiency: 85% AC input frequency: 50 - 60 Hz AC input voltage: 115 - 230 V
Weight & dimensions Width: 150 mm Depth: 140 mm Height: 87 mm
Performance Purpose: PC Power supply unit (PSU) form factor: PS/2 80 PLUS certification: 80 PLUS Bronze ATX version: 2.3
Packaging data Package type: Box Manual: Yes
Ports & interfaces Number of SATA power connectors: 6 Floppy disk drive connector: Yes Peripheral (Molex) power connectors (4-pin): 3 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 4
Other features Warranty card: Yes
Logistics data Harmonized System (HS) code: 84733020
