Design Product colour: Black Cooling type: Active Fan location: Top On/off switch: Yes Fan diameter: 14 cm Number of fans: 1 fan(s)
Power Max output current (+12V): 70.5 A Power Factor Correction (PFC) type: Active Power protection features: Short circuit, Over voltage, Under voltage, Over current, Overload, Overheating Max output current (+3.3V): 22 A Combined power (+5V): 140 W Efficiency: 85% Max output current (-12V): 0.3 A Power factor: 0.9 Max output current (+5V): 22 A Max output current (+5Vsb): 2.5 A Total power: 850 W AC input frequency: 50 - 60 Hz Combined power (+3.3V): 140 W AC input voltage: 115 - 230 V
Weight & dimensions Height: 87 mm Width: 150 mm Depth: 140 mm
Performance Power supply unit (PSU) form factor: PS/2 Purpose: PC 80 PLUS certification: 80 PLUS Bronze ATX version: 2.3
Packaging data Manual: Yes Package type: Box
Ports & interfaces Floppy disk drive connector: Yes PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power connectors (4-pin): 3 Number of SATA power connectors: 9 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes
Other features Warranty card: Yes Harmonized System (HS) code: 84733020
