Design Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 12 cm Product colour: Black
Power Power protection features: Short circuit, Over voltage, Overload AC input voltage: 100 - 240 V Total power: 500 W Input current: 8 A AC input frequency: 47 - 63 Hz Max output current (+5V): 18 A Combined power (+5Vsb): 12.5 W Power Factor Correction (PFC) type: Active Max output current (+3.3V): 18 A Combined power (-12V): 3.6 W Max output current (+5Vsb): 2.5 A Max output current (-12V): 0.3 A Max output current (+12V1): 41 A
Weight & dimensions Depth: 150 mm Height: 86 mm Width: 140 mm Weight: 1.65 kg
Performance Purpose: PC 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: PS/2 ATX version: 2.3
Packaging data Package weight: 2.06 kg
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 Floppy disk drive connector: Yes Cabling type: Non-Modular PCI Express power connectors (6+2 pin): 1 Peripheral (Molex) power cable length: 150, 500 Number of SATA power connectors: 4 Motherboard power connector: 24-pin ATX Floppy drive power connector: 1 SATA power cable length: 150, 500 CPU power cable length: 65 cm PCI Express power cable length: 50 cm CPU power connector (4+4 pin): Yes
Logistics data Harmonized System (HS) code: 84733020
