Design Number of fans: 1 fan(s) Fan diameter: 12 cm Product colour: Black Cooling type: Active
Power Max output current (+5Vsb): 2.5 A Max output current (+5V): 22 A AC input voltage: 100 - 240 V Total power: 700 W Max output current (+12V1): 58 A Max output current (+3.3V): 22 A Input current: 10 A Combined power (+5Vsb): 12.5 W Power protection features: Overload, Short circuit, Over voltage AC input frequency: 47 - 63 Hz Power Factor Correction (PFC) type: Active Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W
Weight & dimensions Weight: 1.72 kg Height: 86 mm Width: 140 mm Depth: 150 mm
Performance 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: PS/2 Purpose: PC
Packaging data Package weight: 2.13 kg
Ports & interfaces CPU power cable length: 65 cm Cabling type: Non-Modular CPU power connector (4+4 pin): Yes Floppy disk drive connector: Yes PCI Express power connectors (6+2 pin): 4 PCI Express power cable length: 50 cm Number of SATA power connectors: 6 Floppy drive power connector: 1 SATA power cable length: 150, 500 Motherboard power connector: 24-pin ATX Peripheral (Molex) power cable length: 150, 500 Peripheral (Molex) power connectors (4-pin): 3
Logistics data Harmonized System (HS) code: 84733020
