Design Fan location: Top Cooling type: Active Product colour: Black Fan diameter: 8 cm Number of fans: 1 fan(s)
Power Max output current (+5Vsb): 3 A Combined power (+12V): 450 W Combined power (+5V): 90 W Max output current (+12V1): 37.5 A Max output current (+5V): 15 A Max output current (-12V): 0.3 A Combined power (+3.3V): 90 W Max output current (+3.3V): 18 A AC input frequency: 47 - 63 Hz Power Factor Correction (PFC) type: Active AC input voltage: 100 - 240 V Input current: 6 A Power protection features: Overheating, Overload, Short circuit, Over voltage, Under voltage, Over current Power factor: 0.9 Efficiency: 90% Total power: 450 W
Weight & dimensions Depth: 125 mm Width: 100 mm Height: 64 mm
Performance ATX version: 2.3 Power supply unit (PSU) form factor: SFX 80 PLUS certification: 80 PLUS Gold Purpose: PC
Certificates Compliance certificates: RoHS
Ports & interfaces PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power connectors (4-pin): 3 Number of SATA power connectors: 6 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes PCI Express connector: Yes Floppy disk drive connector: Yes Floppy drive power connector: 1 ATX power connector (20+4 pin): Yes Cabling type: Fully-Modular
Other features Parallel processing technology support: CrossFire, SLI, CrossFireX
Logistics data Harmonized System (HS) code: 84733020
