Technical details
Sustainability certificates: ErP
Design
Cooling type: Active
Product colour: Black
Fan diameter: 12 cm
On/off switch: Yes
Power
Power protection features: Short circuit, Surge and inrush, Surge protection
Total power: 500 W
Max output current (-12V): 0.4 A
Combined power (+12V): 444 W
Max output current (+5Vsb): 2.5 A
AC input frequency: 50 Hz
Max output current (+12V1): 37 A
Combined power (-12V): 4.8 W
Power Factor Correction (PFC) type: Active
Combined power (+5Vsb): 12.5 W
Power factor: 0.9
Combined power (+3.3V): 100 W
Combined power (+5V): 100 W
Max output current (+3.3V): 20 A
AC input voltage: 200 - 240 V
Input current: 3.5 A
Max output current (+5V): 20 A
Weight & dimensions
Weight: 1.2 kg
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS
Supported motherboard form factors: ATX
ATX version: 2.3
Purpose: PC/Server
Packaging data
Package type: Box
Package weight: 1.45 kg
Certificates
Compliance certificates: RoHS, CE, CB, EAC
Ports & interfaces
EPS power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 150, 450 mm
PCI Express power connectors (6+2 pin): 1
Cabling type: Non-Modular
Motherboard power cable length: 65 cm
Peripheral (Molex) power connectors (4-pin): 2
CPU power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Number of SATA power connectors: 4
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 750, 450, 600
Logistics data
Warranty period: 2 year(s)
Safety warning
Warnings: The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock.
Hazard pictogram(s): GHS07: Harmful, GHS02: Flammable, GHS09: Environmental hazard
