Technical details
Sustainability certificates: ErP
Design
Product colour: Black
Fan diameter: 12 cm
On/off switch: Yes
Power
Power factor: 0.9
Total power: 400 W
AC input frequency: 50 Hz
Combined power (-12V): 4.8 W
Maximum input current (@220V): 3 A
Max output current (+5V): 20 A
AC input voltage: 200 - 240 V
Max output current (+3.3V): 20 A
Input current: 3 A
Power Factor Correction (PFC) type: Active
Combined power (+5Vsb): 12.5 W
Power protection features: Surge and inrush, Surge protection, Short circuit
Max output current (+5Vsb): 2.5 A
Max output current (+12V1): 30 A
Max output current (-12V): 0.4 A
Weight & dimensions
Height: 86 mm
Weight: 1.15 kg
Depth: 140 mm
Width: 150 mm
Performance
ATX version: 2.3
Power supply unit (PSU) form factor: ATX
Supported motherboard form factors: ATX
80 PLUS certification: 80 PLUS
Purpose: PC/Server
Packaging data
Package type: Box
Package weight: 1.4 kg
Certificates
Compliance certificates: RoHS, CE, CB, EAC
Ports & interfaces
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): Yes
EPS power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Cabling type: Non-Modular
Motherboard power cable length: 55 cm
Peripheral (Molex) power cable length: 150, 450 mm
PCI Express power connectors (6+2 pin): 1
Number of SATA power connectors: 4
Peripheral (Molex) power connectors (4-pin): 2
SATA power cable length: 550 mm, 600
Logistics data
Warranty period: 2 year(s)
Safety warning
Warnings: Do not open the case - risk of electric shock., Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Hazard pictogram(s): GHS09: Environmental hazard, GHS07: Harmful, GHS02: Flammable
