Design Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s) Product colour: Silver Fan location: Top On/off switch: Yes
Power Combined power (+5Vsb): 12.5 W Max output current (+3.3V): 18 A Power protection features: Under voltage, Overload, Short circuit, Over voltage Max output current (+5V): 17 A Max output current (+5Vsb): 2.5 A Max output current (+12V1): 38 A Combined power (+3.3V): 110 W Combined power (-12V): 3.6 W Combined power (+12V): 456 W Combined power (+5V): 110 W Max output current (-12V): 0.3 A Power factor: 0.9 Efficiency: 85% Power Factor Correction (PFC) type: Active AC input frequency: 47 - 63 Hz Input current: 4 A AC input voltage: 200 - 240 V Total power: 500 W
Weight & dimensions Width: 140 mm Height: 87 mm Depth: 150 mm
Performance Purpose: PC RoHS compliance: Y Power supply unit (PSU) form factor: PS/2 ATX version: 2.3
Packaging data Package type: Box
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 1 Number of SATA power connectors: 5 Motherboard power connector: 20+4 pin ATX
