Design Cooling type: Active Product colour: Black, Silver Fan diameter: 9 cm
Power AC input frequency: 47 - 63 Hz AC input voltage: 100 - 240 V Input current: 7 A Max output current (+5V): 20 A Power protection features: Short circuit, Over voltage, Overheating, Overload, Under voltage, Over current Combined power (-12V): 3.6 W Total power: 450 W Power Factor Correction (PFC) type: Active Combined power (+5V): 120 W Max output current (+3.3V): 20 A Power factor: 0.9 Combined power (+5Vsb): 12.5 W Max output current (-12V): 0.3 A Combined power (+12V): 450 W Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 120 W Max output current (+12V): 37.5 A
Weight & dimensions Depth: 100 mm Height: 64 mm Weight: 1.5 kg Width: 125 mm
Performance Power supply unit (PSU) form factor: ATX Purpose: PC 80 PLUS certification: 80 PLUS Bronze ATX version: 2.3
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Floppy disk drive cable length: 15 cm SATA power cable length: 250 mm Number of SATA power connectors: 3 PCI Express power connectors (6+2 pin): 2 Motherboard power cable length: 35 cm Peripheral (Molex) power cable length: 150 Cabling type: Non-Modular Floppy drive power connector: 1 PCI Express power cable length: 35 cm Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes
Logistics data Harmonized System (HS) code: 84733020
