Technical details Sustainability certificates: ENERGY STAR Compliance certificates: RoHS
Design Product colour: Metallic Fan diameter: 8 cm Cooling type: Active Number of fans: 1 fan(s) Fan location: Side
Power Max output current (+12V1): 30 A Power protection features: Short circuit, Overload Combined power (+3.3V): 100 W Efficiency: 87% AC input frequency: 47 - 63 Hz Combined power (-12V): 3.6 W Combined power (+5V): 100 W Power Factor Correction (PFC) type: Active Max output current (+3.3V): 16 A Total power: 400 W Max output current (+5Vsb): 2.5 A Combined power (+12V): 360 W Max output current (-12V): 0.3 A AC input voltage: 100 - 240 V Max output current (+5V): 15 A Combined power (+5Vsb): 12.5 W
Weight & dimensions Depth: 140 mm Width: 150 mm Height: 87 mm
Performance Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 2.3 80 PLUS certification: 80 PLUS Bronze
Ports & interfaces EPS power connector (8-pin): Yes Peripheral (Molex) power connectors (4-pin): 3 Floppy drive power connector: 1 Motherboard power cable length: 45 cm Motherboard power connector: 24-pin ATX Number of SATA power connectors: 4 PCI Express power connectors (6-pin): 1 Cabling type: Non-Modular
Logistics data Harmonized System (HS) code: 84733020
