Design Cooling type: Active Fan diameter: 8 cm Number of fans: 1 fan(s) Product colour: Grey
Power Total power: 300 W Power protection features: Overheating, Under voltage, Short circuit, Over voltage, Overload Input current: 6.3 A AC input frequency: 47 - 63 Hz AC input voltage: 115 - 230 V Power factor: 0.9 Max output current (+12V1): 14 A Combined power (-12V): 3.6 W Power Factor Correction (PFC) type: Active Combined power (+3.3V): 95 W Combined power (+5V): 95 W Max output current (+3.3V): 16 A Max output current (+12V2): 15 A Max output current (+5Vsb): 2 A Max output current (-12V): 0.3 A Combined power (+5Vsb): 10 W Max output current (+5V): 15 A
Weight & dimensions Height: 65 mm Weight: 1.07 kg Depth: 175 mm Width: 85 mm
Performance Purpose: PC/Server 80 PLUS certification: 80 PLUS Bronze ATX version: 2.3 Power supply unit (PSU) form factor: TFX
Packaging data Package weight: 1.13 kg
Certificates Compliance certificates: RoHS
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Cabling type: Non-Modular Motherboard power cable length: 30 cm SATA power cable length: 150, 350 mm EPS power connector (4+4 pin): Yes Peripheral (Molex) power cable length: 150, 350 mm Motherboard power connector: 20+4 pin ATX CPU power cable length: 35 cm Floppy drive power connector: 1 Floppy disk drive cable length: 15 cm Number of SATA power connectors: 4
Logistics data Harmonized System (HS) code: 84733020
