Design Cooling type: Active Product colour: Black Fan diameter: 12 cm
Power AC input voltage: 230 V AC input frequency: 47 - 63 Hz Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Combined power (+5V): 130 W Max output current (+3.3V): 22 A Power protection features: Short circuit, Over voltage, Under voltage, Over current, Overload, Overheating Max output current (+12V2): 21 A Combined power (-12V): 3.6 W Total power: 500 W Max output current (+12V1): 24 A Max output current (+5V): 19 A Efficiency: 80% Combined power (+12V): 408 W Max output current (+12V): 12.5 A Combined power (+3.3V): 130 W
Weight & dimensions Depth: 140 mm Height: 87 mm Width: 150 mm
Performance 80 PLUS certification: No Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 2.3
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Number of SATA power connectors: 3 Cabling type: Non-Modular Floppy drive power connector: 1 PCI Express power connectors (6+2 pin): 1 Motherboard power connector: 20+4 pin ATX
