Power Combined power (-12V): 3.6 W Combined power (+5Vsb): 12.5 W Combined power (+3.3V): 120 W Power protection features: Short circuit, Over voltage, Under voltage, Overload Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A AC input voltage: 230 V Max output current (+12V2): 17 A Max output current (+3.3V): 22 A Combined power (+5V): 120 W AC input frequency: 47 - 63 Hz Max output current (+5V): 18 A Power Factor Correction (PFC) type: Active Total power: 400 W Max output current (+12V1): 18 A Input current: 4 A
Weight & dimensions Depth: 140 mm Width: 150 mm Height: 87 mm
Performance 80 PLUS certification: No Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 2.3
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 1 Number of SATA power connectors: 3 CPU P4 connector (4-pin): 1 Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular
