Design Product colour: Black Fan diameter: 13.5 cm Cooling type: Active
Power Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overload, Surge and inrush Max output current (+5Vsb): 3 A Max output current (+12V): 83.3 A Combined power (+5Vsb): 15 W Power Factor Correction (PFC) type: Active Max output current (+5V): 20 A AC input voltage: 100 - 240 V Input current: 13.0-6.5 A Combined power (+12V): 1000 W Max output current (+3.3V): 20 A Total power: 1000 W AC input frequency: 50/60 Hz Combined power (+3.3V): 100 W
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Platinum Purpose: PC ATX version: 3.1 Bearing technology: FDB Power supply unit (PSU) form factor: ATX
Packaging data Package type: Box
Ports & interfaces EPS power connector (8-pin): Yes Cabling type: Fully-Modular Motherboard power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 1 EPS power connector (4+4 pin): Yes Peripheral (Molex) power cable length: 150, 500 PCI Express power connectors (6+2 pin): 3 SATA power cable length: 150, 500 Number of SATA power connectors: 8 Motherboard power connector: 24-pin ATX PCI Express connector: Yes PCI Express power cable length: 65 cm Number of SATA power cables: 3 Number of EPS connectors: 1
