Design Fan diameter: 13.5 cm Cooling type: Active Product colour: Black
Power Max output current (+5Vsb): 3 A Max output current (+3.3V): 20 A AC input voltage: 100 - 240 V Power protection features: Surge and inrush, Short circuit, Over voltage, Under voltage, Overload Max output current (+12V): 100 A Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Combined power (+12V): 1200 W Power Factor Correction (PFC) type: Active Combined power (+5V): 100 W Combined power (+3.3V): 100 W Input current: 15.0-7.5 A Total power: 1200 W AC input frequency: 50/60 Hz
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance Purpose: PC 80 PLUS certification: 80 PLUS Platinum Power supply unit (PSU) form factor: ATX Bearing technology: FDB ATX version: 3.1
Packaging data Package type: Box
Ports & interfaces Cabling type: Fully-Modular EPS power connector (8-pin): Yes Motherboard power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 2 PCI Express connector: Yes Number of SATA power connectors: 8 EPS power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX SATA power cable length: 500, 150 Peripheral (Molex) power cable length: 150, 500 PCI Express power connectors (6+2 pin): 3 ATX Power connector (24-pin): Yes PCI Express power cable length: 65 cm Number of EPS connectors: 1 Number of SATA power cables: 10
