Design
Fan location: Side
Cooling type: Active
On/off switch: Yes
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Product colour: Black
Power
Max output current (+3.3V): 18 A
Efficiency: 85%
Max output current (+12V1): 38 A
Power Factor Correction (PFC) type: Active
Max output current (+5V): 17 A
Combined power (+3.3V): 110 W
Max output current (+5Vsb): 2.5 A
Combined power (+5V): 110 W
Total power: 500 W
AC input frequency: 47 - 63 Hz
AC input voltage: 115 - 230 V
Power protection features: Over power, Overload, Short circuit, Over voltage
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Width: 150 mm
Performance
ATX version: 2.3
Power supply unit (PSU) form factor: ATX
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
Certification: ErP, RoHS, CE, CB, EAC, TÜV
Certificates
Compliance certificates: RoHS
Ports & interfaces
PCI Express power connectors (6+2 pin): 2
Cabling type: Non-Modular
Motherboard power connector: 24-pin ATX
EPS power connector (4+4 pin): Yes
Number of SATA power connectors: 5
Peripheral (Molex) power connectors (4-pin): 3
Logistics data
Harmonized System (HS) code: 84733020
