Design
Product colour: Black
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Power
Total power: 600 W
Power protection features: Overheating, Short circuit, Over voltage, Under voltage, Overload
Combined power (+12V): 552 W
Max output current (-12V): 0.3 A
AC input voltage: 100 - 240 V
Input current: 9 A
Max output current (+5V): 17 A
Combined power (-12V): 3.6 W
Max output current (+5Vsb): 2.5 A
Power Factor Correction (PFC) type: Active
AC input frequency: 47 - 63 Hz
Max output current (+12V): 46 A
Combined power (+5Vsb): 12.5 W
Max output current (+3.3V): 19 A
Power factor: 0.9
Weight & dimensions
Depth: 140 mm
Height: 87 mm
Width: 150 mm
Weight: 1.67 kg
Performance
80 PLUS certification: 80 PLUS Bronze
Supported motherboard form factors: ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Package weight: 2.08 kg
Certification: ErP, CE, CB, EAC, TUV
Certificates
Compliance certificates: RoHS
Ports & interfaces
Peripheral (Molex) power cable length: 150, 500
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 150, 500
PCI Express power cable length: 50 cm
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 2
Number of SATA power connectors: 5
Cabling type: Non-Modular
EPS power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Motherboard power cable length: 65 cm
Other features
EPS cable length: 65 cm
Logistics data
Harmonized System (HS) code: 84733020
