Design
Product colour: Black
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Power
Max output current (+3.3V): 19 A
Max output current (+5Vsb): 2.5 A
Max output current (+5V): 17 A
Power Factor Correction (PFC) type: Active
Combined power (-12V): 3.6 W
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 12.5 W
Max output current (+12V): 54 A
Combined power (+12V): 648 W
AC input voltage: 100 - 240 V
Input current: 10 A
AC input frequency: 47 - 63 Hz
Total power: 700 W
Power protection features: Overload, Overheating, Short circuit, Over voltage, Under voltage
Power factor: 0.9
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Weight: 1.74 kg
Height: 87 mm
Performance
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Bronze
Purpose: PC
Supported motherboard form factors: ATX
Packaging data
Package weight: 2.15 kg
Package type: Box
Certification: ErP, CE, CB, EAC, TUV
Certificates
Compliance certificates: RoHS
Ports & interfaces
EPS power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Motherboard power cable length: 65 cm
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power cable length: 150, 500
Number of SATA power connectors: 6
SATA power cable length: 150, 500
PCI Express power cable length: 50 cm
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power connectors (4-pin): 3
Cabling type: Non-Modular
Other features
EPS cable length: 65 cm
Logistics data
Harmonized System (HS) code: 84733020
Safety warning
Warnings: Avoid contact of the product with water or other liquids., Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Hazard pictogram(s): GHS09: Environmental hazard, GHS07: Harmful, GHS02: Flammable
