Design Number of fans: 1 fan(s) Fan diameter: 12 cm On/off switch: Yes Fan location: Top Cooling type: Active Product colour: Steel
Power Total power: 600 W Combined power (+12V): 552 W Peak power: 600 W Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 120 W Maximum input current (@220V): 4.5 A AC input frequency: 47 - 63 Hz Max output current (-12V): 0.3 A Max output current (+3.3V): 20 A Combined power (+5V): 120 W Max output current (+5V): 20 A AC input voltage: 200 - 240 V Combined power (+5Vsb): 12.5 W Max output current (+12V1): 46 A Combined power (-12V): 3.6 W
Weight & dimensions Depth: 140 mm Weight: 1.42 kg Height: 87 mm Width: 150 mm
Performance ATX version: 2.3 Purpose: PC 80 PLUS certification: 80 PLUS Power supply unit (PSU) form factor: ATX
Packaging data Package weight: 1.56 kg
Certificates Compliance certificates: RoHS, CE
Ports & interfaces Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 4 Peripheral (Molex) power connectors (4-pin): 2 Motherboard power cable length: 55 cm Peripheral (Molex) power cable length: 500 mm, 150 Cabling type: Non-Modular EPS power connector (8-pin): No SATA power cable length: 150, 500 Floppy disk drive connector: Yes Floppy disk drive cable length: 15 cm
Logistics data Harmonized System (HS) code: 84733020
