Technical details
Sustainability compliance: Yes
Design
Cooling type: Active
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Product colour: Silver
Power
Max output current (+5V): 22 A
Power protection features: Under voltage, Under power, Overheating, Short circuit, Over voltage, Overload
Combined power (+5V): 130 W
Max output current (+12V1): 54 A
Combined power (+3.3V): 130 W
Power Factor Correction (PFC) type: Active
Input current: 5 A
AC input voltage: 200 - 240 V
Total power: 700 W
Max output current (+3.3V): 22 A
Combined power (+12V): 648 W
Power factor: 0.9
AC input frequency: 47 - 63 Hz
Weight & dimensions
Depth: 140 mm
Width: 150 mm
Height: 87 mm
Weight: 1.42 kg
Performance
Purpose: PC/Server
80 PLUS certification: 80 PLUS
ATX version: 2.3
Power supply unit (PSU) form factor: ATX
Packaging data
Package weight: 1.57 kg
Certification: CE, CB, EAC, TÜV
Certificates
Compliance certificates: CE
Ports & interfaces
SATA power cable length: 150, 550 mm
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 150, 500 mm
Motherboard power cable length: 55 cm
Number of SATA power connectors: 4
PCI Express power cable length: 50 cm
EPS power connector (4+4 pin): Yes
CPU power cable length: 50 cm
Floppy drive power connector: 1
Motherboard power connector: 20+4 pin ATX
Floppy disk drive connector: Yes
Peripheral (Molex) power connectors (4-pin): 2
Cabling type: Non-Modular
PCI Express power connectors (6+2 pin): 2
Logistics data
Harmonized System (HS) code: 84733020
