Design Fan diameter: 13.5 cm Cooling type: Active Illumination: No Product colour: White
Power AC input frequency: 50/60 Hz Total power: 750 W AC input voltage: 100 - 240 V Max output current (+12V1): 62.5 A Power Factor Correction (PFC) type: Active Max output current (+3.3V): 20 A Max output current (-12V): 0.3 A Combined power (+5V): 100 W Combined power (+3.3V): 100 W Max output current (+5V): 20 A
Weight & dimensions Depth: 150 mm Width: 150 mm Height: 85 mm Weight: 1.96 kg
Performance 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX ATX version: 3.1 Bearing technology: FDB
Packaging data Package weight: 2.43 kg
Ports & interfaces Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 4 ATX Power connector (24-pin): Yes Peripheral (Molex) power connectors (4-pin): 3 Motherboard power connector: 24-pin ATX ATX power connector (20+4 pin): Yes SATA power cable length: 150, 400 CPU power connector (4+4 pin): Yes PCI Express power connectors (12+4 pin) cable length: 600 mm Motherboard power cable length: 60 cm CPU power cable length: 65 cm Number of SATA power connectors: 6 Peripheral (Molex) power cable length: 150, 400 mm PCI Express power connectors (12+4 pin): 1
