Power Max output current (+5V): 18 A AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Total power: 850 W Combined power (-12V): 3.6 W Max output current (+3.3V): 18 A Max output current (+12V1): 70.8 A Combined power (+5Vsb): 15 W Max output current (-12V): 0.3 A
Weight & dimensions Width: 140 mm Depth: 150 mm Height: 86 mm Weight: 1.9 kg
Performance Purpose: PC/Server ATX version: 3.1 80 PLUS certification: 80 PLUS Bronze Power supply unit (PSU) form factor: ATX
Packaging data Package weight: 2.7 kg Package type: Box
Ports & interfaces PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power connectors (4-pin): 3 SATA power cable length: 120, 450 mm Cabling type: Semi-Modular Number of SATA power connectors: 6 CPU power cable length: 70 cm Motherboard power cable length: 65 cm Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes Peripheral (Molex) power cable length: 450 mm, 120 PCI Express power cable length: 60 cm CPU power connector (4+4 pin): Yes
