CLUB3D The CSV-1562 is an USB3.2 Gen1 Type-C Universal Triple 4K30Hz Charging Docking Station and is DisplayLink® Certified. The Universal Charging Dock

Technical details
Compliance certificates: RoHS

Weight & dimensions
Weight: 399 g
Depth: 83 mm
Height: 43 mm
Width: 250 mm

Network
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN: Yes
Compatibility: Lenovo Dell Acer Asus. MSI. Toshiba Apple HP Razer
Certification: FCC, CE and EMI

Performance
Product colour: Black
Country of origin: China
LED indicators: Power
Number of displays supported: 3
Charging function: Yes

Packaging data
Package weight: 282 g
Package width: 298 mm
Package height: 150 mm
Package depth: 92 mm

Packaging content
AC adapter included: Yes
Cables included: USB Type-C to USB Type-C
Drivers included: Yes
Manual: Yes
Mounting brackets included: No
Travel case: No
Anti-slip pads: No

Software
Windows operating systems supported: Windows 11, Windows 10
Mac compatibility: Yes

Ports & interfaces
DisplayPorts quantity: 2
DC-in jack: Yes
USB connector type: USB Type-C, USB Type-A
Connectivity technology: Docking
Line-in: No
HDMI version: 2.0
Combo headphone/mic port: No
Microphone in: Yes
Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
HDMI ports quantity: 3
Headphone outputs: 1
USB Power Delivery (USB PD): Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Headphone connectivity: 3.5 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Line-out: No

Other features
USB data transfer rates: 5000 Mbit/s

Logistics data
Harmonized System (HS) code: 8473 3020

Safety warning
Warnings: Do not use in damp conditions., Do not block the ventilation of the appliance., Do not open the housing of the appliance.

Packaging composition
Plastic packaging weight: 5 g
Total plastic packaging weight: 25 g
Total paper/cardboard packaging weight: 1.15 kg
Paper/cardboard packaging weight: 229 g
