Design Gallium nitride (GaN) transistors: Yes Product colour: Black
Power Port 2 output current: 5 A Port 4 output power: 20 W Port 2 output power: 140 W Port 1 output current: 5 A Input frequency: 50 - 60 Hz Port 4 output current: 3 A Port 3 output current: 4.05 A Minimum output voltage: 3.3 V Maximum output voltage: 55 V Output current (5V): 3 A Output current (12V): 3 A Port 3 output power: 45 W Output current (9V): 3 A Port 1 output power: 140 W Maximum power: 200 W Output current (20V): 5 A Port 5 output power: 18 W Port 5 output current: 3 A Input voltage: 100 - 240 V Output current (15V): 3 A Port 6 output current: 3 A Input current: 2.5 A Port 6 output power: 18 W
Operational conditions Operating temperature (T-T): 0 - 35 °C Operating relative humidity (H-H): 20 - 80% Storage relative humidity (H-H): 10 - 90% Storage temperature (T-T): -20 - 80 °C
Weight & dimensions Depth: 112.5 mm Height: 53.5 mm Width: 53.5 mm Weight: 450 g
Performance Power protection features: Overheating, Short circuit, Overload Fast charging technology: Quick Charge 3.0, Power Delivery USB Type-C ports quantity: 4 Charger compatibility: Universal USB Power Delivery up to: 140 W Charger type: Indoor Number of simultaneously connected devices (max): 6 USB Power Delivery revision: 3.1 USB Power Delivery (USB PD): Yes Fast charging: Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2 Power source type: AC
Packaging data Package height: 150 mm Package weight: 735 g Package width: 160 mm Package type: Box Package depth: 57 mm
Packaging content Cables included: AC, USB Type-C to USB Type-C
Other features Number of products included: 1 pc(s) User guide: Yes
Logistics data Harmonized System (HS) code: 8504408390 Master (outer) case gross weight: 15.2 kg Master (outer) case length: 320 mm Master (outer) case height: 300 mm Master (outer) case width: 335 mm Pallet gross length: 80 cm Pallet gross width: 120 cm Pallet gross height: 152 cm Products per master (outer) case: 20 pc(s) Country of origin: China
