Technical details
Compliance certificates: RoHS, CE
Power
Power source type: DC
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
Width: 202.8 mm
Height: 32.6 mm
Weight: 370 g
Depth: 95 mm
Network
Ethernet LAN data rates: 100, 1000 Mbit/s, 10, 2500
Ethernet LAN: Yes
Networking standards: IEEE 802.3bz
Ethernet LAN (RJ-45) ports: 1
Performance
Compatible memory cards: SD, SDHC, SDXC
Country of origin: China
On/off switch: Yes
Data transfer rate: 10 Gbit/s
Product colour: Black
Cable lock slot type: Nano
Card reader integrated: Yes
Cable lock slot: Yes
Packaging data
Package height: 117.5 mm
Package weight: 1.12 kg
Package width: 257 mm
Package depth: 135.5 mm
Packaging content
Cables included: AC, USB Type-C to USB Type-C
Quick start guide: Yes
AC adapter included: Yes
Software
Mobile operating systems supported: Android 8.0, Android 8.0, Android 7.0, Android 7.0, Android 7.0, Android 12.0, Android 9.0, Android 11.0, Android 14.0, Android 5.0, Android 5.0, Android 13.0, Android 10.0, Android 6.0
Mac operating systems supported: Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.6 Snow Leopard, Mac OS X 10.5 Leopard, Mac OS X 10.9 Mavericks, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.15.3 Catalina, Mac OS X 13.0 Ventura, Mac OS X 10.13 High Sierra, Mac OS X 12.0 Monterey, Mac OS X 10.7.5 Lion, Mac OS X 14.0 Sonoma, Mac OS X 10.14 Mojave, Mac OS X 10.11 El Capitan, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra
Windows operating systems supported: Windows 10 Home, Windows 10 Home x64, Windows 11 Home, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 x64, Windows 11 Enterprise, Windows 11 Pro, Windows 10, Windows 10 IOT Core, Windows 10 Education, Windows 11, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 Pro x64, Windows 11 x64, Windows 10 Education x64, Windows 11 Enterprise x64
Ports & interfaces
DC-in jack: Yes
Headphone connectivity: 3.5 mm
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 4
Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Microphone in: Yes
HDMI ports quantity: 2
HDMI version: 2.0
DisplayPorts quantity: 2
Connectivity technology: Wired
USB Power Delivery revision: 3.0
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB Power Delivery (USB PD): Yes
DisplayPort version: 1.2
USB Power Delivery up to: 100 W
Other features
Master (outer) cases per pallet: 40 pc(s)
Logistics data
Master (outer) case width: 278 mm
Products per master (outer) case: 6 pc(s)
Harmonized System (HS) code: 8471800000
Pallet gross width: 120 cm
Customs product code (TARIC): 8471800000
Pallet gross length: 80 cm
Pallet gross height: 170.2 cm
Master (outer) case gross weight: 11.7 kg
Master (outer) case height: 310 mm
Master (outer) case length: 376 mm
