Technical details
Compliance certificates: RoHS, CE
Features
Data transfer rate (max): 10 Gbit/s
Chipset: ASM3142
UASP support: Yes
Design
Product colour: Green
Hot-swap: Yes
Internal: Yes
Country of origin: China
Operational conditions
Operating relative humidity (H-H): 15 - 90%
Operating temperature (T-T): 0 - 85 °C
Weight & dimensions
Height: 30 mm
Weight: 32 g
Width: 80 mm
Depth: 58 mm
System requirements
Windows operating systems supported: Windows 10 Education x64, Windows 8.1 Enterprise, Windows 10 Enterprise, Windows 10 Home, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 11 x64, Windows 11, Windows 8 x64, Windows 10 Education, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 Enterprise x64, Windows 10 x64, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 10 Pro x64, Windows 8 Enterprise, Windows 8.1, Windows 10 Home x64, Windows 8, Windows 11 Home, Windows 11 Enterprise x64, Windows 11 Enterprise, Windows 11 Pro
Linux operating systems supported: Yes
Packaging data
Package type: Box
Package weight: 120 g
Package height: 140 mm
Package depth: 130 mm
Quick installation guide: Yes
Drivers included: Yes
Package width: 30 mm
Mounting brackets included: Yes
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
Expansion card standard: PCI 3.0
Host interface: PCIe
SATA power connector type: SATA 15-pin
Output interface: USB 3.2 Gen 2 (3.1 Gen 2)
Logistics data
Pallet gross height: 163 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet: 36 pc(s)
Harmonized System (HS) code: 8471800000
Pallet gross width: 120 cm
Master (outer) case gross weight: 3.6 kg
Master (outer) case width: 405 mm
Products per master (outer) case: 30 pc(s)
Master (outer) case height: 205 mm
Master (outer) case length: 340 mm
