Power Port 1 output current: 3.25 A Input frequency: 50 - 60 Hz Maximum output voltage: 20 V Port 2 output current: 3.25 A Minimum output voltage: 5 V Maximum power: 160 W Port 4 output power: 20 W Port 3 output current: 3 A Port 5 output power: 20 W Port 5 output current: 3 A Port 4 output current: 3 A Port 6 output current: 3 A Port 2 output power: 60 W Average active efficiency: 80% Port 3 output power: 20 W Port 6 output power: 20 W Port 1 output power: 60 W Input voltage: 100 - 240 V Input current: 2.5 A
Operational conditions Storage relative humidity (H-H): 5 - 90% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -20 - 80 °C
Weight & dimensions Depth: 216 mm Width: 125 mm Weight: 898 g Height: 74 mm
Performance Fast charging: Yes Charger type: Indoor USB Power Delivery (USB PD): Yes Fast charging technology: Power Delivery 3.0 Number of simultaneously connected devices (max): 7 Charger compatibility: Universal USB Power Delivery revision: 3.0 Wireless charging: No USB Type-C ports quantity: 7 Programmable power supply (PPS): No Power protection features: Short circuit, Over current, Over power Power source type: AC
Packaging data Package height: 76 mm Package width: 185 mm Package weight: 1.31 kg Package depth: 235 mm
Packaging content Cables included: AC, USB Type-C to USB Type-C Manual: Yes
Certificates Compliance certificates: RoHS, CE
Logistics data Master (outer) case length: 400 mm Master (outer) case height: 250 mm Pallet gross width: 120 cm Master (outer) case width: 380 mm Harmonized System (HS) code: 8504408390 Pallet gross height: 190.2 cm Master (outer) case gross weight: 13.8 kg Pallet gross length: 80 cm Products per master (outer) case: 10 pc(s) Country of origin: China
