Features Automatic Voltage Regulation (AVR): Yes Output operation voltage (min): 220 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm UPS topology: Line-Interactive Output power capacity: 1 kVA Output operation voltage (max): 240 V Output power: 600 W Auto-restart: Yes Waveform: Sine Power protection features: Short circuit Input operation voltage (max): 240 V Input operation voltage (min): 220 V
Design Form factor: Compact Product colour: Black International Protection (IP) code: IP20
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Height: 138 mm Width: 96 mm Depth: 286 mm Weight: 5.19 kg
Packaging data Package weight: 5.5 kg Package height: 215 mm Package depth: 357 mm Package width: 161 mm
Packaging content Cables included: Output power cable, USB cable Quick installation guide: Yes
Certificates Compliance certificates: RoHS, CE
Ports & interfaces AC outlet types: C13 coupler AC outlets quantity: 4 AC outlet(s) USB port type: USB Type-B USB port: Yes Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 1
Battery Battery recharge time (90%): 8 h Battery capacity: 7 Ah, 84 Wh Battery voltage: 12 V
Logistics data Products per pallet: 48 pc(s) Harmonized System (HS) code: 8504402000 Master (outer) case width: 179 mm Master (outer) case length: 377 mm Master (outer) case height: 240 mm Country of origin: China Pallet gross width: 120 cm Master (outer) case gross weight: 5.8 kg Products per master (outer) case: 1 pc(s) Pallet gross length: 80 cm Pallet gross height: 2.21 m
