Features Automatic Voltage Regulation (AVR): Yes Waveform: Sine Auto-restart: Yes UPS topology: Line-Interactive Output operation voltage (min): 220 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm Power protection features: Short circuit Output operation voltage (max): 240 V Output power capacity: 1 kVA Input operation voltage (min): 220 V Output power: 600 W Input operation voltage (max): 240 V
Design Form factor: Compact International Protection (IP) code: IP20 Product colour: Black
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Height: 138 mm Weight: 5.19 kg Width: 96 mm Depth: 286 mm
Packaging data Package height: 215 mm Package weight: 5.5 kg Package width: 161 mm Package depth: 357 mm
Packaging content Cables included: Output power cable, USB cable Quick installation guide: Yes
Certificates Compliance certificates: RoHS, CE
Ports & interfaces USB port type: USB Type-B AC outlets quantity: 2 AC outlet(s) Ethernet LAN (RJ-45) ports: 2 USB port: Yes AC outlet types: Type F USB 2.0 ports quantity: 1
Battery Battery recharge time (90%): 8 h Battery capacity: 7 Ah, 84 Wh Battery voltage: 12 V
Logistics data Master (outer) case width: 179 mm Master (outer) case height: 240 mm Master (outer) case gross weight: 5.8 kg Pallet gross width: 120 cm Pallet gross length: 80 cm Master (outer) case length: 377 mm Pallet gross height: 2.21 m Country of origin: China Products per master (outer) case: 1 pc(s) Products per pallet: 48 pc(s) Harmonized System (HS) code: 8504402000
