Features
Output power factor: 1
Output power capacity: 2 kVA
Power protection features: Short circuit
Output power: 2000 W
Input frequency: 50/60 Hz
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Input current Total Harmonic Distortion (THD): 5%
ECO mode: Yes
Output operation voltage (max): 240 V
Maximum current: 10 A
Output operation voltage (min): 220 V
Emergency Power Off (EPO): Yes
Input operation voltage (min): 220 V
Input operation voltage (max): 240 V
Waveform: Sine
UPS topology: Double-conversion (Online)
Design
Cooling type: Active
Display type: LCD
Form factor: Desktop
Product colour: Black
Operational conditions
Operating relative humidity (H-H): 20 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 430 mm
Width: 438 mm
Weight: 17.3 kg
Height: 88 mm
Packaging data
Screws included: Yes
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Rack mount kit: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
USB port: Yes
AC outlet types: C13 coupler
AC outlets quantity: 8 AC outlet(s)
RS-232 ports: 1
USB 2.0 ports quantity: 1
Serial interface: Yes
Serial interface type: RS-232
USB port type: USB Type-B
Programmable sockets: Yes
Battery
Battery voltage: 12 V
Battery capacity: 9 Ah, 108 Wh
Battery recharge time: 4 h
Logistics data
Pallet gross height: 2.15 m
Harmonized System (HS) code: 8504402000
Products per master (outer) case: 1 pc(s)
Pallet gross width: 110 cm
Products per pallet: 32 pc(s)
Master (outer) case width: 550 mm
Pallet gross length: 120 cm
Country of origin: China
Master (outer) case gross weight: 19.5 kg
Master (outer) case height: 226 mm
Master (outer) case length: 566 mm
