Features
Waveform: Sine
Output operation voltage (min): 220 V
ECO mode: Yes
Input current Total Harmonic Distortion (THD): 5%
Output power factor: 1
Maximum current: 16 A
Output power capacity: 3 kVA
UPS topology: Double-conversion (Online)
Output operation voltage (max): 240 V
Emergency Power Off (EPO): Yes
Input frequency: 50/60 Hz
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Input operation voltage (max): 240 V
Input operation voltage (min): 220 V
Output power: 3000 W
Design
Display type: LCD
Form factor: Desktop
Cooling type: Active
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Weight & dimensions
Height: 88 mm
Depth: 610 mm
Width: 438 mm
Weight: 27.3 kg
Packaging data
Screws included: Yes
Packaging content
Cables included: Input power cable, RS-232, USB cable
Rack mount kit: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
RS-232 ports: 1
USB port type: USB Type-B
AC outlet types: C19 coupler, C13 coupler
Serial interface: Yes
USB port: Yes
Programmable sockets: Yes
Serial interface type: RS-232
Power plug: C19 coupler
AC outlets quantity: 9 AC outlet(s)
USB 2.0 ports quantity: 1
Battery
Battery recharge time: 4 h
Battery capacity: 108 Wh, 9 Ah
Battery voltage: 12 V
Logistics data
Master (outer) case width: 550 mm
Master (outer) case gross weight: 30.3 kg
Master (outer) case length: 746 mm
Products per pallet: 16 pc(s)
Harmonized System (HS) code: 8504402000
Products per master (outer) case: 1 pc(s)
Pallet gross length: 110 cm
Pallet gross width: 76 cm
Master (outer) case height: 226 mm
Pallet gross height: 2.14 m
Country of origin: China
