Features Output power: 6000 W Audible alarm(s): Yes Output power factor: 1 Input frequency: 50/60 Hz Input current Total Harmonic Distortion (THD): 5% Output operation voltage (max): 240 V Output power capacity: 6 kVA UPS topology: Double-conversion (Online) ECO mode: Yes Waveform: Sine Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm Input operation voltage (max): 300 V Output operation voltage (min): 208 V Input operation voltage (min): 80 V
Design Form factor: Rackmount/Tower Display type: LCD Product colour: Black
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): -15 - 50 °C
Weight & dimensions Weight: 59.4 kg Height: 131 mm Depth: 480 mm Width: 438 mm
Packaging data Package type: Box
Certificates Compliance certificates: RoHS, CE
Ports & interfaces USB port type: USB Type-B Serial ports quantity: 1 USB port: Yes Emergency Power Off (EPO) connector: Yes Serial interface type: RS-232 Serial interface: Yes USB 2.0 ports quantity: 1
Battery Battery capacity: 7 Ah, 84 Wh Number of batteries supported: 16 Battery recharge time: 4 h Battery voltage: 192 V
Logistics data Customs product code (TARIC): 8504406090 Products per master (outer) case: 1 pc(s) Country of origin: China Pallet gross length: 57.5 cm Master (outer) case length: 890 mm Master (outer) case height: 572 mm Pallet gross width: 89.5 cm Master (outer) case gross weight: 66 kg Master (outer) case width: 570 mm Harmonized System (HS) code: 850440 Pallet gross height: 126 cm
