Features
Waveform: Sine
ECO mode: Yes
UPS topology: Double-conversion (Online)
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Input current Total Harmonic Distortion (THD): 5%
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Output power: 1800 W
Output operation voltage (max): 240 V
Output power capacity: 2 kVA
Output power factor: 0.9
Power protection features: Short circuit
Maximum current: 10 A
Input operation voltage (max): 240 V
Input operation voltage (min): 220 V
Emergency Power Off (EPO): Yes
Design
Form factor: Tower
Display type: LCD
Product colour: Black
Cooling type: Active
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Weight & dimensions
Height: 225 mm
Width: 151 mm
Depth: 394 mm
Weight: 17.1 kg
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Serial interface: Yes
Serial interface type: RS-232
USB port type: USB Type-B
USB port: Yes
AC outlets quantity: 6 AC outlet(s)
RS-232 ports: 1
AC outlet types: C13 coupler
USB 2.0 ports quantity: 1
Battery
Battery recharge time: 4 h
Battery voltage: 12 V
Battery capacity: 9 Ah, 108 Wh
Logistics data
Pallet gross length: 100 cm
Master (outer) case width: 241 mm
Master (outer) case height: 313 mm
Pallet gross width: 120 cm
Master (outer) case gross weight: 17.6 kg
Harmonized System (HS) code: 8504402000
Pallet gross height: 12.6 cm
Master (outer) case length: 510 mm
Products per pallet: 30 pc(s)
Country of origin: China
Products per master (outer) case: 1 pc(s)
