Features
Output operation voltage (min): 220 V
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Input current Total Harmonic Distortion (THD): 5%
Output operation voltage (max): 240 V
Input frequency: 50/60 Hz
Power protection features: Short circuit
Output power capacity: 3 kVA
Maximum current: 16 A
ECO mode: Yes
Output power factor: 0.9
UPS topology: Double-conversion (Online)
Waveform: Sine
Output power: 2700 W
Emergency Power Off (EPO): Yes
Input operation voltage (max): 240 V
Input operation voltage (min): 220 V
Design
Form factor: Tower
Cooling type: Active
Display type: LCD
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Weight & dimensions
Depth: 416 mm
Height: 342 mm
Weight: 21.3 kg
Width: 196 mm
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
USB port: Yes
Serial interface type: RS-232
AC outlet types: C13 coupler, C19 coupler
USB port type: USB Type-B
RS-232 ports: 1
Serial interface: Yes
AC outlets quantity: 5 AC outlet(s)
Power plug: C19 coupler
USB 2.0 ports quantity: 1
Battery
Battery recharge time: 4 h
Battery capacity: 9 Ah, 108 Wh
Battery voltage: 12 V
Logistics data
Country of origin: China
Pallet gross height: 12.6 cm
Products per master (outer) case: 1 pc(s)
Master (outer) case height: 458 mm
Master (outer) case width: 295 mm
Pallet gross length: 100 cm
Pallet gross width: 120 cm
Harmonized System (HS) code: 8504402000
Products per pallet: 16 pc(s)
Master (outer) case length: 519 mm
Master (outer) case gross weight: 22.3 kg
