Features Input current Total Harmonic Distortion (THD): 5% Output power: 5400 W Input frequency: 50/60 Hz Audible alarm(s): Yes Output operation voltage (min): 208 V Output operation voltage (max): 240 V Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm Output power capacity: 6 kVA Output power factor: 0.9 Input operation voltage (max): 300 V Input operation voltage (min): 110 V UPS topology: Double-conversion (Online) Waveform: Sine ECO mode: Yes
Design Product colour: Black Form factor: Tower
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): -15 - 50 °C
Weight & dimensions Height: 702 mm Weight: 54 kg Width: 196 mm Depth: 412 mm
Packaging data Package type: Box
Certificates Compliance certificates: RoHS, CE
Ports & interfaces Serial ports quantity: 1 USB port: Yes USB 2.0 ports quantity: 1 Serial interface: Yes USB port type: USB Type-B Serial interface type: RS-232 Emergency Power Off (EPO) connector: Yes
Battery Battery voltage: 192 V Battery capacity: 84 Wh, 7 Ah Number of batteries supported: 16 Battery recharge time: 4 h
Logistics data Pallet gross height: 126 cm Pallet gross width: 110 cm Pallet gross length: 76 cm Harmonized System (HS) code: 850440 Products per master (outer) case: 1 pc(s) Country of origin: China Master (outer) case gross weight: 55.6 kg Master (outer) case length: 568 mm Master (outer) case width: 348 mm Master (outer) case height: 810 mm Customs product code (TARIC): 8504406090
