Features
Waveform: Sine
UPS topology: Double-conversion (Online)
Output operation voltage (max): 240 V
Input current Total Harmonic Distortion (THD): 5%
Output power factor: 0.9
Emergency Power Off (EPO): Yes
Crest factor: 3:1
Output operation voltage (min): 220 V
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Maximum current: 10 A
ECO mode: Yes
Input power factor: 0.99
Input operation voltage (max): 240 V
Input operation voltage (min): 220 V
Efficiency (ECO mode): 95%
Audible alarm(s): Yes
Power protection features: Short circuit, Overload
Output power capacity: 1 kVA
Input frequency: 50/60 Hz
Output power: 900 W
Design
Built-in fan: Yes
Display type: LCD
Form factor: Tower
Product colour: Black
Cooling type: Active
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 191 mm
Depth: 327 mm
Weight: 10.1 kg
Width: 140 mm
Packaging data
Package type: Box
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
AC outlet types: Type F
USB port type: USB Type-B
Emergency Power Off (EPO) connector: Yes
AC outlets quantity: 3 AC outlet(s)
RS-232 ports: 1
USB port: Yes
USB 2.0 ports quantity: 1
Battery
Cold start: Yes
Battery voltage: 12 V
Battery capacity: 9 Ah, 108 Wh
Battery recharge time: 4 h
Logistics data
Master (outer) case height: 277 mm
Master (outer) case gross weight: 10.5 kg
Pallet gross length: 100 cm
Harmonized System (HS) code: 8504406090
Master (outer) case length: 440 mm
Master (outer) case width: 217 mm
Pallet gross width: 120 cm
Pallet gross height: 126 cm
Products per master (outer) case: 1 pc(s)
Country of origin: China
