Features
Output power: 1800 W
Audible alarm(s): Yes
Power protection features: Short circuit, Overload
Maximum current: 10 A
ECO mode: Yes
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Input power factor: 0.99
Output operation voltage (max): 240 V
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
UPS topology: Double-conversion (Online)
Efficiency (ECO mode): 95%
Output power capacity: 2 kVA
Output power factor: 0.9
Emergency Power Off (EPO): Yes
Crest factor: 3:1
Input operation voltage (max): 240 V
Waveform: Sine
Input operation voltage (min): 220 V
Design
Form factor: Tower
Cooling type: Active
Product colour: Black
Display type: LCD
Built-in fan: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Weight & dimensions
Height: 225 mm
Width: 151 mm
Weight: 17.1 kg
Depth: 394 mm
Packaging data
Package type: Box
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
USB 2.0 ports quantity: 1
AC outlets quantity: 4 AC outlet(s)
RS-232 ports: 1
Emergency Power Off (EPO) connector: Yes
AC outlet types: Type F
USB port type: USB Type-B
USB port: Yes
Battery
Battery voltage: 12 V
Battery capacity: 9 Ah, 108 Wh
Battery recharge time: 4 h
Cold start: Yes
Logistics data
Country of origin: China
Products per master (outer) case: 1 pc(s)
Pallet gross length: 100 cm
Master (outer) case width: 241 mm
Pallet gross width: 120 cm
Harmonized System (HS) code: 8504406090
Master (outer) case height: 313 mm
Master (outer) case length: 510 mm
Master (outer) case gross weight: 17.6 kg
Pallet gross height: 126 cm
