Features
Maximum current: 16 A
Output power factor: 0.9
Output operation voltage (min): 220 V
ECO mode: Yes
Output power capacity: 3 kVA
Input frequency: 50/60 Hz
Audible alarm modes: Alarm when on battery, Fault, Overload alarm, Battery replacement, Low battery alarm
Audible alarm(s): Yes
Power protection features: Short circuit, Overload
Crest factor: 3:1
Output power: 2700 W
Waveform: Sine
Input power factor: 0.99
Output operation voltage (max): 240 V
Efficiency (ECO mode): 95%
UPS topology: Double-conversion (Online)
Input operation voltage (max): 240 V
Input operation voltage (min): 220 V
Design
Display type: LCD
Form factor: Tower
Built-in fan: Yes
Cooling type: Active
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Weight & dimensions
Height: 342 mm
Width: 196 mm
Weight: 21.3 kg
Depth: 416 mm
Packaging data
Package type: Box
Packaging content
Cables included: Input power cable, RS-232, USB cable
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
RS-232 ports: 1
USB port type: USB Type-B
Emergency Power Off (EPO) connector: Yes
USB port: Yes
AC outlet types: Type F
AC outlets quantity: 4 AC outlet(s)
USB 2.0 ports quantity: 1
Battery
Battery capacity: 9 Ah, 108 Wh
Battery voltage: 12 V
Battery recharge time: 4 h
Cold start: Yes
Logistics data
Harmonized System (HS) code: 8504406090
Master (outer) case width: 295 mm
Master (outer) case length: 519 mm
Pallet gross length: 100 cm
Products per master (outer) case: 1 pc(s)
Country of origin: China
Master (outer) case height: 458 mm
Pallet gross height: 126 cm
Pallet gross width: 120 cm
Master (outer) case gross weight: 22.3 kg
