Design
Fan location: Top
On/off switch: Yes
Cooling type: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Product colour: Black
Power
Power Good signal delay range: 100 - 150 ms
Max output current (+12V): 100 A
Total power: 1200 W
Combined power (+3.3V): 120 W
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Max output current (-12V): 3.6 A
Combined power (-12V): 3.6 W
Max output current (+3.3V): 22 A
Combined power (+5V): 120 W
Efficiency: 90%
Combined power (+12V): 1200 W
Hold time: 16 ms
Combined power (+5Vsb): 15 W
Max output current (+5V): 22 A
AC input frequency: 50/60 Hz
Power protection features: Under voltage, Overheating, Short circuit, Over voltage, Over power
Number of +12V rail(s): 1
AC input voltage: 100 - 240 V
Input current: 7.5 - 15 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 150 mm
Width: 150 mm
Height: 86 mm
Performance
ATX version: 3.1
Bearing technology: FDB
Power supply unit (PSU) form factor: ATX
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Ports & interfaces
Cabling type: Fully-Modular
Motherboard power cable length: 60 cm
PCI Express power connectors (6+2 pin): 6
SATA power cable length: 600 mm, 700 mm, 500
Motherboard power connector: 24-pin ATX
Number of SATA power connectors: 9
Peripheral (Molex) power cable length: 600 mm, 700 mm, 500
Peripheral (Molex) power connectors (4-pin): 3
ATX Power connector (24-pin): Yes
EPS power connector (4+4 pin): Yes
Number of EPS connectors: 2
PCI Express power connectors (12+4 pin): 1
Number of SATA power cables: 3
PCI Express power connectors (12+4 pin) cable length: 600 mm
