Design
Product colour: White
Fan connector: 7-pin
Radiator material: Aluminum
Illumination colour: Red, Blue, Green
Number of fans: 3 fan(s)
Illumination LED: Yes
Power
Rated current: 0.26 A
Pump power consumption: 7.2 W
Rated voltage: 12 V
Fan power consumption: 3.12 W
Safety current: 0.37 Ah
Pump voltage: 12 V
Weight & dimensions
Tube length: 40 cm
Pump height: 6.29 cm
Package height: 142 mm
Radiator height: 2.72 cm
Radiator depth: 39.4 cm
Package width: 229 mm
Radiator width: 12 cm
Weight: 1.65 kg
Package weight: 2.73 kg
Package depth: 450 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Pump depth: 8.36 cm
Pump width: 7.85 cm
Performance
Supported processor sockets: LGA 1155 (Socket H2), LGA 1151 (Socket H4), LGA 1200 (Socket H5), LGA 1156 (Socket H), LGA 1700, LGA 1150 (Socket H3), Socket AM5, Socket AM4, LGA 1851
Type: Liquid cooling kit
Maximum airflow: 71.9 cfm
Pump noise level: 25 dB
Bearing type: Rifle bearing
Rotational speed (min): 650 RPM
Airflow: 122.4 m³/h
Pulse-width modulation (PWM) support: Yes
Fan diameter: 12 cm
Fan noise level (max): 27.2 dB
Maximum air pressure: 1.86 mmH2O
Fan's mean time to failure (MTTF): 40000 h
Rotational speed (max): 1750 RPM
Pump connector: 3-pin + 4-pin
Pump motor speed (max): 3200 RPM
Suitable location: Processor
Pump's mean time to failure (MTTF): 35000 h
Quantity per pack: 1 pc(s)
Logistics data
Master (outer) case width: 465 mm
Master (outer) case height: 310 mm
Master (outer) case length: 475 mm
Products per master (outer) case: 4 pc(s)
