Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
Power
Efficiency: 88%
Combined power (+12V): 648 W
Total power: 650 W
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over power
Max output current (-12V): 0.3 A
Max output current (+12V): 54 A
Combined power (+3.3V): 120 W
Power Factor Correction (PFC) type: Active
Combined power (-12V): 3.6 W
Max output current (+3.3V): 19 A
Combined power (+5V): 120 W
Power Good signal delay range: 100 - 150 ms
Max output current (+5Vsb): 3 A
Combined power (+5Vsb): 15 W
Max output current (+5V): 19 A
Hold time: 16 ms
AC input frequency: 50/60 Hz
AC input voltage: 200 - 240 V
Input current: 5 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 86 mm
Weight: 1.65 kg
Width: 150 mm
Depth: 140 mm
Performance
Mean time between failures (MTBF): 100000 h
Purpose: PC/Server
Bearing technology: HDB
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Bronze
Packaging data
Package weight: 2.05 kg
Package depth: 245 mm
Package height: 110 mm
Package width: 190 mm
Certification: ErP 2014 Lot 3
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, China Compulsory Certification (CCC), UKCA, RCM, BIS, EAC
Ports & interfaces
Peripheral (Molex) power cable length: 700, 550, 400 mm
Motherboard power cable length: 50 cm
EPS power connector (4+4 pin): Yes
PCI Express power cable length: 62 cm
Cabling type: Non-Modular
Motherboard power connector: 24-pin ATX
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 4
SATA power cable length: 550 mm, 400 mm, 700
EPS power connector (8-pin): Yes
Peripheral (Molex) power connectors (4-pin): 3
Other features
EPS cable length: 67 cm
Logistics data
Master (outer) case length: 570 mm
Master (outer) case height: 215 mm
Master (outer) case width: 260 mm
Products per master (outer) case: 5 pc(s)
Master (outer) cases per pallet (air): 32 pc(s)
